Name: Megaroyal Pump
Brand: Shengtian Group
Availability: InStock
Rating: 5 (1 reviews)

Megaroyal Pump

Powerful and reliable, Megaroyal Pump is designed for high volume chemical injection and transfer, with a 100hp (75kw) motor. With leak-proof performance in even the most critical industrial process environments, it is ideal for industries requiring “zero leakage” and precise control of process-critical liquids.

Description

Megaroyal Pump Manufacturer,Megaroyal Pump Supplier,Megaroyal Pump Stockist In China

　　Powerful and reliable, Megaroyal Pump is designed for high volume chemical injection and transfer, with a 100hp (75kw) motor. With leak-proof performance in even the most critical industrial process environments, it is ideal for industries requiring “zero leakage” and precise control of process-critical liquids.

Product Description

　　Flow range: 28-700L/H

　　Pressure Range: 10-220 Bar

　　Temperature range :-22°F to +194°F ( -30°C to +90°C)

　　Control: Manual operation)

　　Motor power: 1.5KW

　　Standard power supply: 380V, 50/60HZ, 3 Phase

　　Protection degree: IP54

Megaroyal Pump Parameter

Model	50Hz			60 Hz			Pressure		Plunger Dia. (mm)	Diaphragm Dia. (mm)	Stroke Length (mm)	Power kW(HP)	Inlet&Outlet Size	Connection Size
Model	Flow (lph)	Flow (gph)	SPM	Flow (gph)	Flow (lph)	SPM	(Bar)	(Psi)	Plunger Dia. (mm)	Diaphragm Dia. (mm)	Stroke Length (mm)	Power kW(HP)	Inlet&Outlet Size	Connection Size
JYSD40/35	40	11	100	13	48	120	350	5075	16	110	40	3(4)	DN10	DN10 WN Flange
JYSD63/35	63	17	150	20	76	180	350	5075	16	110
JYSD80/30	80	21		25	96		300	4350	18	130
JYSD100/26	100	26		32	120		260	3770	20	130
JYSD125/23	125	33		40	150		230	3335	22	130			DN15	DN15 WN Flange
JYSD160/18	160	42		51	192		180	2610	25	130
JYSD240/12	240	63		76	288		120	1740	30	130
JYSD260/11	260	69		82	312		110	1595	32	130
JYSD340/8.5	340	90		108	408		85	1233	36	150			DN20	DN20 RF Flange
JYSD420/6.8	420	111		133	504		68	986	40	150
JYSD540/5.6	540	143		171	648		56	812	45	170
JYSD670/4.5	670	177		212	804		45	653	50	170
JYSD820/3.8	820	217		260	984		38	551	55	170			DN25	DN25 RF Flange
JYSD980/3.2	980	259		311	1176		32	464	60	180
JYSD1100/2.8	1100	291		349	1320		28	406	63	180
JYSD1160/2.6	1160	306		368	1392		26	377	65	190			DN32	DN32 RF Flange
JYSD1350/2.3	1350	357		428	1620		23	334	70	190
JYSD1550/2.0	1550	410		491	1860		20	290	75	200
JYSD1800/1.8	1800	476		571	2160		18	261	80	220

Megaroyal Pump Applications And Specifications

　　The right solution for a wide range of industries, including oil and gas, chemical and petrochemical processing, water treatment, and general industry. Capable of handling flows up to 12,680 gph or 211 gpm (48 m³/h or 800 L/min) with discharge pressures up to 3,655 psi (252 bar). Despite its high performance, the MEGAROYAL is surprisingly compact being up to 25% smaller when compared to other competitive brands, making it perfect when space is limited.
