| CAPACITIES [Q] TO: | 1200 m3/h |
| HEADS [H] TO: | 100 m |
| OPERATING TEMPERATURE: | -20 bis 110 °C |
| OPERATING PRESSURES [P] TO: | 10 bar |
| DISCHARGE NOZZLE FROM: | DN 25 to DN 250 |
| MOTOR RATINGS TO: | 30 kW |
| MAIN MATERIALS | PP PE-UHMW PVDF |
| IMPELLER | Closed Semi-open Vortex impeller (depending on pump size) |
| SHAFT SEAL | Metal-free mechanical seal with SSiC rotating and stationary seal rings Available as single or double mechanical seal |
| EXPLOSION PROTECTION (ATEX) | Meets the requirements of Directive 2014/34/EU |
