Name: Drill Pipe
Brand: Shengtian Group
Availability: InStock
Rating: 5 (1 reviews)

Description

API 5DP oilfield drilling rig seamless G105 NC26 2 3/8" drill pipe

　　Drill pipe is a crucial component in drilling operations, used to transmit power and drilling fluids to the drill bit. It's essentially a hollow, thin-walled steel pipe, often with special threaded ends called tool joints, that allows for easy connection and disconnection during drilling.

　　drill pipe comply with the provisions under the Standards API SPEC 5DP and API SPEC7. The grade of steel for the drill pipe will

　　be determined according to the requirements of Group 1 and Group 3 of API SPEC 5DP.

　　(i.e.: Group 1--Grade E; Group 3--Grade X-95, Grade -G-105 and Grade -S-135)

　　As per requirements of customers, drill pipe joints at the same level will be provided, and manufactured drill pipe joints will

　　comply with the provisions under the Standard API SPEC 7.

　　Seamless G105 Drill Pipe

　　Nc50 API Drill Pipe

Size		Weight	Grade	Wall thickness		Upset types
Inch	mm	Weight	Grade	Inch	mm	Upset types
2 3/8	60.3	6.65	E.X.G.S	0.28	7.11	EU
2 7/8	73	10.4	E.X.G.S	0.362	9.19	IU,EU
3 1/2	88.9	9.5	E	0.254	6.45	IU,EU
3 1/2	88.9	13.3	E.X.G.S	0.368	9.35	IU,EU
3 1/2	88.9	15.5	E	0.449	11.4	IU,EU
3 1/2	88.9	15.5	X.G.S	0.449	11.4	EU,IEU
4	101.6	14	E.X.G.S	0.33	8.38	IU,EU
4 1/2	114.3	13.75	E	0.271	6.88	IU,EU
4 1/2	114.3	16	E.X.G.S	0.337	8.56	EU,IEU
4 1/2	114.3	20	E.X.G.S	0.43	10.92	EU,IEU
5	127	16.25	X.G.S	0.296	7.52	EU
5	127	19.5	E	0.362	9.19	IEU
5	127	19.5	X.G.S	0.362	9.19	EU,IEU
5	127	25.6	E	0.5	12.7	IEU
5	127	25.6	X,G,S	0.5	12.7	EU,IEU
