Name: Drill Bits
Brand: Shengtian Group
Availability: InStock
Rating: 5 (1 reviews)

Description

We specialize in all kinds of tools such as HSS twist drill bits, electric hammer drill bits, masonry drill bits, woodworking drill bits, HSS hole saws, HSS taps, TCT saw blades, diamond saw blades, diamond core drills and some other power tool accessories and parts. We are located in Danyang City, Jiangsu Province, China, which provides easy access to air, water and land transportation.

Based on rich experience, advanced technology and professional skills, our products can always maintain the first rate quality as well as competitive prices. In recent years, our products have sold well in domestic and foreign markets, well received by customers in America, Europe, the Middle East, Indonesia and other countries and regions.

PRODUCT CATALOGS

Colored Multifunction Construction Drill Bits for Masonry

1. Profile: milled;
2. Overall fine heat treatment;
3. High quality standard YG8C carbide tip;
4. Fine #40 Cr material body.
Milled Masonry Drill Bits Chrome Blasted.
Material: Tip, high quality YG8C carbide tip; body, fine #40 Cr;
Sizes available: dia from 3-40mm; length from 50-650mm.
Manufacturing process: milled.
Flute types available: R type, U type, L type, double flutes type etc.

* made of high carbon steel with industrial grade carbide tip for long life and efficient drilling.
* milled slow spiral for quick, easy debris removal.
* galvanized surface finish for corrosion resistance.
* hardened core for extra strength and reduced breakage.
* for use with percussion drills.
* for drilling in masonry, concrete, rock, artificial stone, and breeze blocks

1. Aplication: Used for Drilling Concrete, Granite, Brick, Block, Tile,Marble. Masonry
2. Manufacturing Process: Roll Forged, Milled
3. Material: 40Cr Steel and YG8C Carbide
4. Shank: Straight( Parallel, Reduced Shank,Hex Shank, 1/4" Quick Change Shan, 3 Flats Shank, TAPCON.
5. Flute: High Helix Flutes, L Type Flutes,R Type flutes,U Type Flutes,etc. are available
6. Surface: Zinc Plated, Nickle Plated, Chrome Plated, Black & White,Sandblasted, White & Copper Plated.
7. Standard: Q/321181 RFD004 OR DIN8039
8. Size(mm): 360mm - 251000mm
9. Packing: Individually packed in PVC pouch, Round Tube, Skin Card, Double Blister(Clamshell).
10. Item No.: DM-HS1026

We can supply the product in single pcs as well as in sets with decent package.
The products are produced according to DIN / ANSI standards, we are also capable for OEM and ODM production.
Press "contact supplier" for favorable prices now!

For Masonry and Brick Wall
Masonry Drill Bits
Manufacturing	Surface Finish					Flute
Manufacturing	Sand Blasted	Chorme	Nickle	Zinc	Brass	Single	Round	Square	Double	High Helix
Roll Forged				√
Milled	√	√	√	√	√	√	√	√	√	√
Standards	DIN8039
Material	Tip:YG8C Tungsten Carbide;Shank:45# Carbon Steel/ 40Cr Steel
Shank	Straight(Parallel), Reduced Shank, Hex Shank, 1/4"Quick Change Shank,3 Flats Shank

Product Information

MASONRY DRILL BITS SPECIFICATION:
Diameter		Flute Length	Overall Length
Size(mm)	Size(inch)	mm	mm
3	1/8	30	60
4	5/32	40	75
5	3/16	50	85
6	15/64	60	100
6.5	1/4	60	100
7	9/32	60	100
8	5/16	80	120
9	11/32	80	120
10	3/8	80	120
11	7/16	85	150
12	15/32	85	150
13	1/2	95	150
14	9/16	95	150
15	19/32	95	150
16	5/7	95	150
17	11/16	95	150
18	11/16	105	160
19	3/4	105	160
20	25/32	105	160
22	7/8	105	160
24	15/16	105	160
25	1	105	160

PACKAGING & SHIPPING

One pc in PVC bag or Plastic tube,Paper card With PVC Skin

CERTIFICATE
In order to overcome the challenges that support solidarity and cooperation to create a better future

WIDELY USED
Household, Industrial Use

Colored Multifunction Construction Drill Bits for Masonry
