BFV308
Butterfly Valve
Medium:Water
Standard:EN593/AWWA C504/MSS SP-67/MSS SP-68
Pressure:CLASS 125-300/PN10-25/200-300PSI
Material:CI,DI
Type:Wafer Type
Dimensions Data
| DN | A | B | ΦC | D | L | L1 | H | ΦK | ΦG | 4-ΦN | QXQ |
| DN50 | 60 | 138 | 35 | 153 | 47 | 240 | 32 | 65 | 50 | 6.7 | 11X11 |
| DN65 | 72 | 140 | 35 | 155 | 50 | 240 | 32 | 65 | 50 | 6.7 | 11X11 |
| DN80 | 85 | 140 | 35 | 180 | 50 | 240 | 32 | 65 | 50 | 6.7 | 11X11 |
| DN100 | 102 | 160 | 55 | 205 | 56 | 265 | 32 | 90 | 70 | 10.3 | 14X14 |
| DN125 | 120 | 175 | 55 | 240 | 59 | 265 | 32 | 90 | 70 | 10.3 | 14X14 |
| DN150 | 137 | 189 | 55 | 265 | 59 | 265 | 32 | 90 | 70 | 10.3 | 17X17 |
| DN200 | 169 | 230 | 55 | 320 | 63 | 366 | 32 | 90 | 70 | 10.3 | 17X17 |
| DN250 | 200 | 260 | 72 | 385 | 68 | 366 | 45 | 125 | 102 | 14.5 | 22X22 |
| DN300 | 230 | 306 | 72 | 450 | 73 | 366 | 45 | 125 | 102 | 14.5 | 27X27 |
| DN350 | 251 | 333 | 72 | 480 | 86 | 366 | 45 | 125 | 102 | 14.5 | 28X28 |
| DN400 | 311 | 418 | 72 | 555 | 91 | 366 | 45 | 125 | 102 | 14.5 | 28X28 |
One-piece wafer body style or full lug style for terminal service. Both body styles offer bidirectional sealing as standard in conformance, Cast iron and stainless steel can be selected, Customizable product color and logo
Wide Variety Of Disc Material Choices
Precision machined and hand polished disc to provide a minimum torque and longer seat life. Customizable color material
Actuator Mounting Flange OR Handle
The top flange is drilled as per EN ISO 5211 to accommodate direct mounting of a wide range of actuators. Operating handles with different materials and colors
Wide Choice Of Seating Materials
Smooth finished disc flats mate with seat to give a highly efficient primary seal that prevents leakage into the shaft area. Customizable seat material, such as EPDM, NBR, PTFE and so on.
Optional Electric Actuated and Pneumatic Actuated
