Description

AWWA C504 Class 125 Butterfly Valve Manufacturer,Butterfly Valve Supplier

Name: BFV201-150 Butterfly Valve
Brand: Shengtian Group
Availability: InStock
Rating: 5 (1 reviews)

BFV201-150
Butterfly Valve
Medium:water
Standard:EN593/AWWA C504/MSS SP-67
Pressure:CLASS 125-300/PN10-25/200-300PSI
Material:CI,DI
Type:Double flange type,U type

Material :

BODY	CI, DI, WCB, WCC, LCB, LCC, CF8, CF8M, CF3, CF3M, C95400, C95800, SAF2205, SAF2507, F51, 1.4529^^
DISC	CF8, 304, CF3, 304L CF8M, 316, CF3M, 316L, SAF2205, SAF2507, F51, 1.4529, C95400, C95500, C95800, MONEL^..
SEAT	BUNA-N, NBR, EPDM, HYPALON, NEOPRENE, FKM, PTFE, RPTFE, NATURAL RUBBER^^
STEM	F410, F420, F430, F431, F304, F316, MONEL 400, MONEL K500^^

Technical Parameters:

Size	DN32-DN600	DN650-DN3000
Working pressure	16Bar	10Bar
Shell	24Bar	15Bar
Seal(Air)	6Bar	6Bar
Operating Temperature	-40ºC~+160ºC
Operating Environment	Ballast and bilge system Chemical processing Desalination plants Drilling rigs Drinking water Dry powder Food and beverage Gas plants HAVC Mining industry Paper industry Sand handling Seawater Sugar industry Thermo technical water treatment Waste water
Driving method	Hand Lever Worm Gear Electric Pneumatic

Dimensions Data

Size	A	B	C	ΦF	ΦD	4-ΦN	Φd	H	M1	ANSI 150
Size	A	B	C	ΦF	ΦD	4-ΦN	Φd	H	M1	ΦJ	Φk	n-Φk1
3"	146	89	127	90	70	10	12.7	32	3.18	191	152.5	4-19
4"	177	112	127	90	70	10	15.9	32	4.78	229	190.5	8-19
6"	203	140	127	90	70	10	25.4	32	7.94	279	241.5	8-22
8"	235.5	170	152	125	102	12	28.6	45	7.94	343	298.5	8-22
10"	267	200	203	125	102	12	34.9	45	12.7	406	362	12-25
12"	312	230	203	150	125	14	38.1	45	12.7	483	432	12-25
14"	343	256	203	150	125	14	44.5	45	12.7	533	476	12-29
16"	372	299	203	210	165	23	50.8	50	12.7	597	539.5	16-29
18"	402	327	203	210	165	23	57.2	50	15.88	635	578	16-32
20"	437	352	203	210	165	23	63.5	60	15.88	699	635	20-32
24"	498.5	420	203	210	165	23	76.2	70	15.88	813	749.5	20-35

Suitable Temperature: -45C to 230º C
